General
Power Supply : 8x1.5V AA Batteries
Product Size : 180mmx140mmx65mm/7.1”x5.5"x2.56”
Product Weight : 900g/1.98lb
Certificate : CE / ETL / RoHS
Safety Rating : CAT III 1000V / CAT IV 600V
Features
Auto Power Off
LOCK
MIN/MAX/AVG
Compare function
Timer function
Storage Function
DAR
PASS
Backlight
Relative Measurement
Data Hold
Low Battery Display
SPECIFICATION
| Specification | ||||
| Output Voltage | Range | Resolution | Test Current | Accuracy |
| 250V (0~20%) | 0~20MΩ 20~200MΩ 200~250MΩ | 0.01MΩ 0.1MΩ 1ΜΩ | 1mA @250k | ±(3%+5) |
| 500V (0~20%) | 0~20MΩ 20~200MΩ 200~500MΩ | 0.01MΩ 0.1MΩ 1ΜΩ | 1mA @500k | ±(3%+5) |
| 1000V (0~20%) | 0~20MΩ 20~200MΩ 200~1000MΩ | 0.01MΩ 0.1MΩ 1ΜΩ | 1mA @1000k | ±(3%+5) |
| 2500V (0~20%) | 0~2000MΩ 2000MΩ~20GΩ 20GΩ~100GΩ 100GΩ~300GΩ | 1MΩ 0.01GΩ 0.1GΩ 0.1GΩ | 3mA @2500k | ±(3%+5) ±(5%+20) ±(10%+20) ±(20%+20) |
| DC Voltage Test | 200V/1000V | 0.1V/1V | ±(0.5%+5) | |
| AC Voltage Test | 200V/750V (50~60Hz) | 0.1V/1V | ±(1.5%+5) | |
| Resistance | 20Ω 200Ω | 0.01Ω 0.1Ω | 1mA | ±(1%+5) ±(1%+5) |
